Sonance SonAmp DSP2-150 Mark II Digital DSP Amplifier
•High resolution 24 bit/96 kHz processing DAC capable of 4608 KBPS audio playback.
•IP and IR controllable via SONARC for the ultimate in installation flexibility.
•Powerful, audiophile grade Class-D amplification, rated and certified at 8 and 4 ohms & stable to 2 ohms.
•Convection cooled, fanless* design allows for direct stacking with no air gap for even greater power density.
*(DSP 2-750 has a variable speed fan)
•Compact form factor allows for space savings in the equipment rack with ample power to the speakers.
•Class-D design is 93% efficient for maximum power output with minimal power usage. Meets EU power saving standards.
•Full array of input/output connectivity for maximum installation flexibility: Line input/loop outputs; IP, IR, audio and voltage triggers; Ethernet jack for network connectivity.
•Terminal blocks will accept up to 12AWG speaker cable for longer runs and higher performance.
•Bridgeable channels for applications when even more power is required.
•Certified to worldwide safety standards. (TUV to UL standards, CE, RCM, C-Tick, RoHS, WEEE). Meets FCC standards.
•Rack ears and removable feet included.
Technical Specifications:-
Number of Channels:
2 (1 stereo pair)
Output Power - 8 ohms:
150 Watts RMS per channel (all channels driven)
Output Power - 4 ohms:
224 Watts RMS per channel (all channels driven)
Output Power - 8 ohms (Bridged):
473 Watts
Frequency Response:
5Hz - 50kHz, bandwidth limited
Operating Voltage:
100 - 12V@60Hz, 220 - 240V@50Hz
Rack Space Requirement:
1U - 1/2 Rack Width
Dimensions With Feet (WxHxD):
8 5/8" x 2 1/8" x 16 13/16" (219mm x 54mm x 427mm)
Dimensions No Feet (WxHxD):
19" x 1 3/4" x 16 13/16" (482mm x 44mm x 427mm)
Shipping Weight:
11lbs (5.0kg)
Accessories
