The MPA-502 is an incredible five-channel power amplifier with an impressive heritage. Introduced as the MPA-500 in 1992, it became the power amplifier that was utilized to assist in writing THX's original amplifier specification. Based on an audiophile configuration, where a mammoth power supply resides in its own chassis (MPS-502) independent of the chassis housing the five amplifier modules, the MPA-502 is the most powerful multi-channel power amplifier in the world. In fact, when operating on a standard 115V AC outlet, you cannot even force the amplifier into clipping because to do so requires 28 amperes of wall current. The MPA-502 incorporates a 2500 Watt custom torroidal power supply in combination with 500,000µF of capacitance. This huge power reservoir ensures that the MPA-502 has plenty of punch for even the most dramatic scenes. Suffice it to say, that the MPA-502 is as good as it gets. For systems requiring back surround speakers (7.1), ADA provides the exact same amplifier modules in a two-channel version, the PF-2502.
Features:
•5 Channel Power Amplifier
•Balanced And Unbalanced Audio Inputs
•200 Watts Per Channel @ 8 Ohms
•400 Watts Per Channel @ 4 Ohms
•600 Watts Per Channel @ 2 Ohms
•2 Ohm Minimum Safe Impedance
•0.01% Total Harmonic Distortion @ 8 Ohms
•Low Voltage Trigger
•3U Fan Cooled Chassis x 2
•IC Controlled Slow Turn-On Circuit
•Separate Power Supply With Military Grade Interconnect
•Torroidal Power Transformer
•1800 Watts Maximum Power Consumption
•3072 BTU's/Hr Thermal Dissipation
•Circuit Breaker Protected
•MPA-502 46 lbs. 5.25"H x 19"W x 19"D
•MPS-502 52 lbs. 5.25"H x 19"W x 16.5"D
