AVR20 - AV Receiver
The design of the HDA range draws upon all of Arcam’s experience as one of the UK’s most respected audio companies, to produce Arcam’s best performing range of audio products yet – using the best quality components and engineering practices, the HDA range is designed and built to give you years of listening enjoyment.
Stunning Realism, Immersive Sound
The AVR20 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With an impressive 16-channel surround solution and featuring all the latest CODECs from Dolby, DTS and IMAX Enhanced, the AVR20 exemplifies sound quality and engineering excellence.
The AVR20 features the efficient class AB amplification for a level of transparency that delivers the most captivating sound. Audiophile listening experiences are optimised with full 16-channel Dirac calibration on board as well as simple streaming with a mobile device using the native app of choice via Apple Airplay2 or Google Chromecast.
Features:-
• Dolby Atmos & DTS:X 9.1.6 decoding
• 4K (UHD) HDMI2.0b with HDCP2.2
• 7 HDMI inputs, 3 HDMI outputs, eARC compatible
• Dirac Live® for Arcam room correction
• ESS 9026PRO audiophile DAC
• Class AB power amplification - Uses toroidal transformer
• Wifi / Ethernet, RS232 and IR control
• Google Cast/UPnP capability for streaming audio
• Bluetooth
• Free MusicLife iOS UPnP and control app
Technical Specifications:-
Continuous power output, per channel, 8Ω/4Ω:
2 channels driven, 20Hz ‑ 20kHz, < 0.02% THD: 110W/175W
2 channels driven, 1kHz, 0.2% THD: 125W/190W
7 channels driven, 1kHz, 0.2% THD: 90W/110W
Residual noise & hum (A-wtd): < 0.15mV
Stereo Line Inputs:-
Maximum input: 4.5V rms
Nominal sensitivity: 1V, 2V, 4V (user adjustable)
Input impedance: 47kΩ
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct: 100dB/110dB
Frequency response: 20Hz—20kHz ± 0.2dB
Preamplifier Outputs:-
Nominal output level: 1V RMS (max. 5V RMS)
Output impedance: 560Ω
THD+N (20Hz—20kHz): –100dB
Headphone Output:-
Maximum output level into 32Ω: 5Vrms
Output impedance: < 1 00Ω
General:-
Mains voltage: 110–120V or 220–240V, 50–60Hz
Power consumption (maximum): 1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical): 100W (Thermal dissipation approx. 340 BTU/hour)
Power consumption (standby): < 0.5W
Dimensions W x D (including speaker terminals) x H (including feet): 433 x 425 x 171mm
Weight (net): 16.6kg
Weight (packed): 19.9kg
Supplied accessories:-
Mains lead
Remote control with 2 x AAA batteries
Manual
DAB/FM aerial
3 x WiFi/Bluetooth antennas
Calibration microphone
USB cable
