An integrated amplifier for today’s world.
Roon Ready®, Spotify Connect®, Dolby Digital Decoding®, Wi-Fi, and Room EQ are only the beginning.
Discover power, performance, convenience and value.
The new DS-A101-G integrated amplifier strikes the perfect balance of high-quality audio reproduction, features, and value. The small form factor allows for easy placement while still providing technologies and convenience not found on competing products.
Technical Specifications:-
Amplifier: BASH Digital Fidelity Tracking Amplifier
Power output Continuous:
2 x 80 Watts 2 channels driven into 4 ohms @ 1kHz
2 x 40 Watts 2 channels driven into 8 ohms @ 1kHz
2 x 70 Watts 2 channels driven into 2 ohms @ 1kHz
Power output burst (CEA 2010*):
120 Watts 1 channel driven into 4 ohms @ 1kHz
65 Watts 1 channel driven into 8 ohms @ 1kHz
170 Watts 1 channel driven into 2 ohms @ 1kHz
Power and THD+N, 1kHz:
4 ohms 70 Watts @ .07%
8 ohms 40 Watts @ .03%
Signal-to-Noise Ratio: (Full Power Digital input): 101dB
Broadband Frequency Response: 20Hz to 40kHz +/- 1.8dB
Analog inputs: 2
Digital inputs: 2 total; 1 optical / 1 coaxial (192kHz 24-bit)
Ethernet Input: 1
Wi-Fi: Yes
Subwoofer Output: 1
Pre-Amp Outputs: 1 (L/R)
Bluetooth audio: Yes
Audio Decoding: Dolby Digital
Streaming Services: Discovery, Roon Ready, Spotify Connect, AirPlay, Bluetooth, DLNA
Display: OEL
App Control: Yes, iOS and Android control app. A Bluetooth 4.0 low-energy Android or iOS device is required to use this application.
Room Correction: ABC (Auto Blend & Calibrate)
All specifications subject to change.
Power Consumption:
Power Off 120Vac: .86W
Auto-Off 120Vac: 5.45W
