Sublime sound served up with serious power.
ELAC’s new Navis Series answers every minimalist audiophile’s dream of a no-compromise powered speaker driven by best-inclass amplifiers that are truly deserving of the name “high end.” While most powered speakers rely on Class D digital designs, ELAC engineers build in 300 watts of pure analog amplification— for maximum power and exceptional sound. Add the Discovery Connect wireless transmitter to your system, and Navis becomes a wireless speaker that lets you enjoy streaming content without a cable in sight.
Custom-Designed Midrange/Tweeter
One reason the Navis sounds so natural is because of its
in-house developed transducer, a 4-inch aluminum midrange
driver with a concentrically mounted 1-inch soft-dome tweeter.
Combined, this signature configuration lets Navis set the
performance standard for its class.
Custom-Designed Woofer
Navis’s single woofer reproduces bass with authority, thanks
to the special design of its driver. Developed in-house, the
5¼-inch aluminum cone is the ideal structural material, specified
for its ability to deliver slam, punch and accurate low-frequency
fundamentals.
Beautiful Cabinets
Navis’s elegant design integrates perfectly with any interior.
Its enclosure has a fine-furniture finish, available in Gloss
Black, Gloss White and Wood Veneer. A dedicated floor stand
completes the installation, and is recommended for optimum
performance.
Powerful Trifecta
Inside each Navis Bookshelf Loudspeaker
is a Tri-Amp Pure Analog Amplifier,
employing three separate amps for each
transducer: a 160-watt BASH AB amplifier
for the woofer, a 100-watt BASH AB
amplifier for the midrange, and a 40-watt
Class AB amplifier for the tweeter. A total
amplifier power of 300 watts ensures that
each transducer is optimally—and amply—
powered, eliminating clipping and
crossover distortion, and driving each
transducer with authority. Specs like a
110 dBA signal-to-noise ratio and 100 uV
noise floor could only come from such audiophile-quality amps!
Flexible Connections
Local inputs include balanced XLR, RCA and Wireless, when
used with ELAC’s Discovery Connect wireless transmitter to
stream Discovery, Spotify Connect, Bluetooth, AirPlay and Roon.
Just switch Wireless “Off” for a no-compromise analog input and
output.
Technical Specifications:-
Speaker type: 3-Way Powered
Tweeter: 1″ Soft Dome Concentrically Mounted
Midrange: 4″ Aluminum
Woofer: 3 x 5-1/4″ Aluminum
Frequency Response: 43Hz – 28kHz
Crossover Frequency: 2.2kHz / 260Hz
Total Amplifier Power: 300 Watts Total
Bass Amplifier: 160 Watt Bash Amplifier
Midrange Amplifier: 100 Watt Bash Amplifier
Tweeter Amplifier: 40 Watt Class AB Amplifier
Inputs: RCA / XLR / AirX² Wireless
Cabinet finishes: Gloss Black, Gloss White, Gloss Ebony Emara
Height: 40.35″
Width: 7.44″
Depth: 9.45″
Net weight (each): 46.3lbs
