Krell Duo 300 XD
Krell's New XD Technology
Krell’s “XD” (Xtended Dynamics, Xtended Dimensionality, Xtended Detail) upgrade for the iBias amplifiers takes an already great sounding amplifier and raises its performance to the next level. “XD” is a classic example of Krell’s continuous R & D efforts reaping benefits across multiple product lines. During the development of the K-300i Integrated Amplifier we discovered substantial sonic improvements by lowering the output impedance below traditional norms. So we applied this technique to our existing line of amplifiers and the improvement was so substantial that it required a unique designation, hence, “XD.”
It was no simple matter to just lower the output impedance. This affects the amplifier’s stability and transient response so each stage prior to the output stage had to be re-tuned to work optimally with the lower output impedance. This lower output impedance exerts more control over the speaker drivers and damps out unwanted vibrational modes, allowing a more accurate reproduction of the original signal.
Technical Specifications:-
Frequency response:
20 Hz to 20 kHz +0, -0.13 dB
0.5 Hz to 100 kHz +0, -3 dB
Signal-to-noise ratio:
> 98 dB, wideband, unweighted, referred to full power output
> 116 dB, "A"-weighted
Gain: 26.2 dB
Total harmonic distortion:
< 0.045% at 1 kHz, at 400 W, 8 Ω
< 0.17% at 20 kHz, at 400 W, 8 Ω
Input Impedance:
Single-ended: 100 kΩ
Balanced: 200 kΩ
Input sensitivity:
Single-ended or balanced: 2.4 V RMS
Output power:
300 W RMS at 8 Ω
540 W RMS at 4 Ω
Output voltage:
138 V peak-to-peak
49 V RMS
Output current:
16 A peak
Slew rate:
40 V/μs
Output impedance:
< 0.007Ω, 20 Hz to 20 kHz
Damping factor:
> 1140, 20 Hz to 20 kHz, referred to 8 Ω
Power consumption:
Standby: 4 W
Idle: 180 W
Maximum: 1600 W
Heat output:
Standby: 13.7 BTU/hr.
Idle: 615 BTU/hr.
Maximum: 5677 BTU/hr.
Inputs:
2 single-ended via RCA connector
2 balanced via XLR connector
Outputs:
2 pairs binding posts
Dimensions:
17.1 in. W x 7.65 in. H x 21.10in. D
434 mm W x 194 mm H x 536mm D
Weight:
80 lbs., 3.64 kg (shipping)
70 lbs., 31.8 kg (unit only)
