The RX-7 is ideally suited to drive high-quality home theater and multi-channel music systems. Based on the design of the larger ZX-7, the RX-7 has a fully balanced topology. Due to its low distortion and quiet operation, it is capable of exceptional refinement of fine detail and resolution of low-level sonic details. And with a rated output of 200 watts into seven channels, the RX-7 has more than enough power to drive almost any system to reference levels with ease.
SPECIFICATIONSOutput Power - 200W RMS per channel into 8 from 20Hz to 20kHz
Frequency Response - 20Hz to 20kHz +0.1dB/-0.2dB
THD - Less than 0.05% at full rated FTC power 20Hz - 20kHz
Less than 0.005% at full FTC power at 1kHz
Signal-to-Noise Ratio
Greater than -105dB below rated full rated power A-weighted
IM Distortion - Less than 0.03% at full rated power
Crosstalk - Greater than -80dB @ 1kHz (30kHz bandwidth)
Damping Factor - Greater than 200 @ 20Hz (ref 8)
Input Sensitivity - 1.6 volts for 200W out into 8
Input Impedance - Minimum 10K
Gain - 28dB ± 0.5dB
