CI Pro P65-IW
Quick Specs:-
◾In-wall applications.
◾1" X-PAL™ tweeter with exclusive Perforated Phase-Aligning (PPA™) Tweeter Lens and Reduced Edge Diffraction (RED™) Technology.
◾6.5" mineral-filled polypropylene bass/midrange driver with overmolded ART™ surround and die-cast aluminum chassis.
◾Bezel-Free Micro-Perf Grille.
v
Technical Specifications:-
Design:
2-driver, 2-way in-wall, SHOCK-MOUNT™ Isolation Mounting System, die-cast aluminum baffle
Crossover:
2nd-order electro-acoustic at 2.5 kHz
Frequency Response On-Axis:
±3 dB from 70 Hz - 22 kHz
Frequency Response 30° Off-Axis:
±3 dB from 70 Hz - 18 kHz
High Frequency Driver:
1" (2.5cm) X-PAL™ dome, ferro-fluid damped / cooled, Reduced Edge Diffraction (RED™) Technology, Perforated Phase-Aligning (PPA™) Tweeter Lens
Mid/Bass Frequency Driver:
6.5" (16.5cm) mineral-filled polypropylene cone, overmolded Active Ridge Technology (ART™) surround, die-cast aluminum chassis
Low Frequency Extension:
35 Hz
Sensitivity Room / Anechoic:
91.5 dB / 87.5 dB
Impedance:
Compatible with 8 ohms
Suitable Amplifier Power Range:
15-120 W
Maximum Input Power:
90 W
Finishes:
White, paintable grille, black/grey speaker
Weight:
8.2 lbs. (3.7 kg)
Overall Dimensions:
11.3125" (28.7cm) Height
8.125" (20.6cm) Width
3.875" (9.8cm) Depth
Cut-Out Dimensions:
10.1875" (25.9cm) Height
7" (17.8cm) Width
Minimum Mounting Depth: 3.375" (8.6cm)
Depth required is the distance
between 1/2" drywall, or similar material.
