Persona SUB
Six 8” Driver Subwoofer with 1700W Continuous / 3400W Peak Power
Persona Sub is specially designed to match the aesthetics of the Persona Series, and to deliver a wallop of deep bass effects.
Six 8-inch woofers, featuring durable overmolded surrounds, are radially aligned in Paradigm’s signature hexagonal Vibration- Canceling Design Architecture enclosure. Powered by a 1700W Ultra-Class-D amplifier (capable of 3400W dynamic peaks), and an array of Paradigm bass enhancements like advanced DSP, efficient venting and superior power supply switching, this sub adds depth, clarity and bass precision to your Persona audio system. Achieve well-blended musical bass down to an astonishing 12Hz. Use two or more for a truly moving audio experience!
Engineered to “take on the persona” of your audio performance, each speaker virtually disappears behind an unprecedented level of realism and transparency. Whether you’re passionate about classic two-channel stereo, or an enveloping multichannel home theater system, Persona’s combination of innovation, performance and elegance introduces luxury in an indulgent new class of loudspeaker.
Precision components and superior materials, including Persona’s exclusive Truextent® Beryllium tweeter and mid-range driver system, allow Persona 5F to deliver unprecedented transparency and dynamic performance levels with a slightly smaller footprint.
Designed, engineered, and Completely Crafted in Canada, Persona celebrates the technological abilities of Paradigm engineering, untamed. Its exceptional craftsmanship and meticulous attention to detail makes a bold, beautiful statement. No other speaker in this class can match the performance innovation of Persona.
Technical Specifications:-
Design:
6-driver, acoustic suspension hexagonal vibration cancelling subwoofer
Crossover:
Low pass crossover: Variable 35 Hz - 150 Hz; Bypass Option; variable 0-180 deg phase
Amplifier:
1,700 W RMS (3,400 W Dynamic Peak)
Room Correction:
Anthem Room Correction - ARC™, with included calibrated microphone
Frequency Response
On-Axis:
+/- 2dB from 19Hz - 220Hz (by pass option)
Frequency Response
30° Off-Axis:
+/- 2dB from 19Hz - 220Hz (by pass option)
Low Frequency Driver:
Six 8" (203mm) high-excursion X-PAL™ drivers, overmolded Active Ridge Technology (ART™) surrounds, 1-1/2" (38mm) four-layer long-excursion voice coils, high-temperature composite Nomex® formers, advanced spiders, 9.2-lb (4.16 kg) hard ferrite magnet / motor structure, AVS™ die-cast heatsink chassis
Low Frequency Extension:
12Hz
Sensitivity
Room / Anechoic:
100 mV (mono) / 100 mV (mono)
Impedance:
RCA: 10k ohms; XLR: 20k ohms
Finishes:
High Gloss: Vanta Black, Harmony White
Metallic Gloss: Aria Blue, Sonic Silver
Weight:
118 lbs. (53.6 kg)
Dimensions
HxWxD:
20.5" × 20.25" × 18.875"
(52.5cm × 51.2cm × 48cm)
