With the increased popularity of computers as source, this Link D1 USB DAC allows consumers to enjoy listening to digital music sources from a computer (Windows or Mac) via USB connection. This product is USB 1.1 and 2.0 compliant. No custom USB drivers or software programs are required. This device supports sampling frequencies ranging from 32kHz to 192kHz and incorporates a high quality digital-to-analogue converter (DAC). It can also serve as an USB interface simply to convert the data of music files from your computer to SPDIF signal for use with outboard DAC’s.
Quad Link D1 24Bit/192kHz DAC Specifications:
| Model |
Link D-1 USB DAC |
| General description |
Digital-to-analogue converter |
| Design philosophy and core technology |
USB / SPDIF interface & DAC |
| DAC |
Crystal CS4398 |
| Sampling Frequency |
44.1kHz - 192kHz |
| Maximum Sampling Frequency |
192kHz |
| Digital input |
1 x USB (asynchronous mode) |
| Digital output |
1 x coaxial, 1 x Toslink optical |
| Output voltage |
4V (unbalanced) |
| Output impedance |
100O (unbalanced) |
| Frequency response |
20Hz - 20kHz (+/-0.2dB) |
| Dynamic range |
110dB |
| Height |
130mm |
| Width |
108mm |
| Depth |
42mm |
| Carton size |
600 x 400 x 340mm |
| Net weight |
0.7kg |
| Gross weight |
1.39kg |
Power requirements
(depending on region) |
230V (50 ~ 60Hz), etc. |
| Safety regulation conformity |
CE, UL, CB, CCC, PSE, etc. |
| Standard accessories |
power cord, remote control handset, batteries, user manual, certificate, USB link (Type A, Type B), etc. |
|
