NERO 4S UHD HDR projector
Enjoy the clarity and realism of the top of the line of SIM2’s single-chip DLP®-based projectors: UHD (Ultra High Definition) images with SIM2’s all-new NERO 4S UHD HDR projectors. Featuring Texas Instruments’ DLP® 4K UHD chipset, NERO 4S UHD HDR delivers exceptional 4K images, high brightness, and an accurate, vibrant color palette.
The NERO 4S UHD HDR is available in a black glass cabinet with matte black accents, a unique design touch to suit any room style.
Designed for use with medium / large Home Theater and Entertainment installations.
And, for Large Theaters and Entertainment installations, SIM2 has designed the SIM2 Dual NERO 4S UHD HDR: a dual projection system for an amazing mix of power flexibility and redundancy, coupled with top-notch performance.
The SIM2 NERO 4S UHD HDR projectors deliver class-leading picture quality through the partnership of the latest 4K UHD DLP® chipset from Texas Instruments, super high-precision and resolution optics and SIM2’s advanced video processing technology, for a lucid and colorful viewing experience. DLP® from Texas Instruments is Hollywood’s choice of technology for movie theaters and conveys extraordinary image quality that brings out the smallest details - even during high-speed sequences – with assured, long-lasting performance.
The flexibility of the SIM2 NERO 4S UHD HDR is truly unique: featuring a super power 2x zoom and a super wide lens shift, it suits perfectly almost all large theater applications
The 4K UHD chipset
The 4K UHD DMD chip's fast-switching speed (over 9,000 times per second) allows each mirror to render two distinct and unique pixels per frame to display 8.3 million pixels for each frame - four times the resolution of Full HD 1080p. The result is an image with extreme corner-to-corner clarity and sharply defined details.
Technical Specifications:-
LIGHT ENGINE
DLP® Type and Image Resolution:
NERO 4S UHD HDR: 1-chip DMD 0.67” UHD - 4K UHD (3840x2160 pixels): 8.3M pixels
DUAL NERO 4S UHD HDR: Dual projection system: 2x custom-tuned projectors - 1-chip DMD 0.67” UHD - 4K UHD (3840x2160 pixels): 8.3M pixels
Dynamic Range: HDR compliant, with dedicated Display Modes and 4 presets to cover the screen size from 100 to 160 inches
Lens: Super high definition pure-glass lens with telecentric optics
High-quality glass 1.36 ÷ 2.68 (+/- 5%)
Zoom range (ratio): 1.96x
Throw Distance 2,5m ÷ 9m for focus range, optimized @ 2.98m
Focal Length (f) (mm) 19.975(Wide) ~ 39.811 @ 2.98m
F Number 1.71(Wide) ~ 2.59 (Tele) @ 2.98m
Lens resolution: 93 lines per millimeter
Light Source and brightness(1):
NERO 4S UHD HDR: 450W lamp (dimmable) - up to 6.000 Ansi Lumens
DUAL NERO 4S UHD HDR: 2x 450W lamp (dimmable) > 10.000 Ansi Lumens
Lamp life expectancy(2): 3000 hours typical in ECO mode
Adjustable iris: 10 apertures memorized
SIM2 Perfect Fit and autofocus tracking (NOT for DUAL NERO 4S)
Remote Info function: SIM2 Customer Care 4
Live Colors Calibration 4.0
INSTALLATION
Lens Throw ratio (+/- 5%): 1.36-2.68:1
Lens Shift: Manual - Horizontal +/-30% offset (+/- 5%) Vertical+/-75% offset(+/- 5%)
Zoom & Focus: Motorized with position encoders
SIM2 Perfect Fit Setup zoom and focus values in ten different memories (NOT for DUAL NERO 4S)
INPUTS/OUTPUTS:
1 x RGBHV / YCbCr (D-Sub 15-pin female)
2 x HDMI (v.1.4a - HDCP 1.4)
1 x HDMI (v.2.0a - HDCP 2.2)
1 x HDMI audio/video out (v.1.4a - HDCP 1.4)
1 x Display Port v.1.2
1x VGA / 3x YCrCb Component
1 x USB type A for Firmware upgrade
1 x RJ45 for control communications through internal web pages
1 x RS232 for control communications
2 x IR receivers
2 x 12V, 200mA (+/- 10%), Triggers output
1 x Wired IR receiver
ELECTRONICS AND GENERAL SPECIFICATIONS
Horizontal & Vertical scan freq.: 15-91 KHz/24-120 Hz
UHD: @ 24/25/30/50/60/70/72/75 Hz
Controls: IR remote control, Keypad on rear panel, RS-232 Serial commands, RJ45 ethernet commands and internal web pages
Mains voltage range: 100-240 +/-10% (50/60 Hz)
Power Consumption: Bright: Typ. 585W, max 644W @ 110VAC, Typ. 555W, max 611W @ 220VAC;
Eco: Typ. 470W, max 517W @ 110VAC, Typ. 450W, max 495W @ 220VAC
Stand-by: < 0.5 W @ 110/220VAC
Projector weight: approx. 32 Kg. / 70.5 lbs
Projector dimensions (WxHxD): 528 x 215 x 582 mm (20.8” x 8.5” x 22.9”)
