VP12SUB-NC In-Wall subwoofers combines elegant, modern visual design with uncompromised bass performance for home theatres and multi media solutions.
The VP Series Subwoofers feature an innovative low profile driver with an ultra low distortion motor and 4” diameter voice coil. The VP12SUB-NC In-Wall subwoofer incorporates a 12” woofer. Dual central mount spiders are used in both models to maximize the movement of the laminated carbon fibre honeycomb woofer cone.
VP Series Subwoofer enclosures are constructed from a combination of 1/2” and 1” MDF for superior isolation of bass and extruded aluminium bracing for minimal obstruction of airflow inside the enclosure. Mass damping of front and back walls of each enclosure and long strand fibreglass internal damping for standing wave dissipation is also incorporated. In addition, a floating enclosure design minimizes vibration transfer to adjoining rooms. Both enclosures fit in a standard 2 x 4 stud bay and a blank preconstruction plate is included for easy installation.
In-Wall New Construction Subwoofer
•Designed for installation during the construction or renovation process
•Enclosure is positioned behind the wall to deliver unprecedented performance with minimal visual intrusion
•State-of-the-art design and cutting-edge materials deliver the bass of a large cabinet subwoofer without sacrificing floor space
•Available in 10" or 12" models to suit any sized room or available wall space
•Provides a consistent aesthetic with other Visual Performance Series speakers
•Custom-tuned amplifiers ensure optimum sonic performance
•Low profile driver
•1.5” of peak to peak travel
•Ultra low distortion motor
•4” diameter voice coil
•Dual central mount spiders to maximize the linear movement of the cone
•Laminated carbon fibre honeycomb cone
•Die-cast basket
•Visual Performance grille
Specifications
Woofer
12” (305mm) laminated carbon fibre cone with a rubber surround
Frequency Response
25Hz - 250Hz ±3dB
Impedance
8 ohms nominal
Sensitivity
90dB (2.83V/1) meter
Grille
Perforated steel
Requirements
Requires Cinema SUB12-500 acoustic enclosure, sold separately
Requires Cinema SUB12-500 amplifier, sold separately
Dimensions (WxHxD)
12 3/8” x 12 3/8” x 3 5/32” (314mm x 314mm x 80.2mm)
Grille Dims (WxHxD)
15” x 15” x 5/32” (381mm x 381mm x 4mm)
Shipping Weight
19 lbs (8.6kg) each
