The Stealth Acoustics model LR3G is a three-way, full-range loudspeaker system that becomes completely invisible after installation. The loudspeaker has a rigid frame that attaches directly to standard structural framing. The paintable active diaphragm face is bonded to the frame of the speaker panel, creating an active area surrounded by a stable mounting area. Installation instructions are shown on a paper overlay that is to be removed before installation. The overlay can also be used as a cutting template for retrofitting the speakers into existing wallboard.
The LR3G may be installed in either the wall or ceiling and on-site finishing options include latex paint, light wallpaper, fabrics and selected texture coats. There is no need for special vellums or other nonstandard wallboard finishing materials. Advanced finishing methods such as Venetian plaster and select veneers are supported using special techniques.
The Stealth Acoustics LR3G incorporates an acoustically coupled high quality, high-power 8” cone woofer and direct coupled 25 mm neo-magnet high-frequency motors. Advanced internal carbon fiber materials allow for smooth frequency extension to 20 kHz. When the LR3G is installed in standard insulated 2” x 4” framing and allowed to function in a full 8 foot stud bay, frequency response below 40 Hz can be achieved. The LR3G contains three independent protection circuits (low, mid-range and high frequency sections) that automatically reset upon reduction of excessive amplifier power.
Specifications:-
Frequency Response:
40Hz to 20kHz
Power Capacity:
200 watts RMS
75 watts minimum recommended power
Protection:
Three independent self-resetting devices (low, mid-range and high frequency)
Sensitivity:
81 dB (1 watt / 1 meter)
Driver Components:
High frequency:
1” (25 mm) neodymium motor
Midrange frequency:
Two 1” (25 mm) neodymium motors
Low-frequency:
1.5” (38 mm) voice coil, 8” (203 mm) woofer
Ceramic 20 oz. (622 gr) magnet
System Impedance:
8Ω nominal
Polar Dispersion:
170 degrees vertical and horizontal
Dimensions:
Width: 15-7/8” (403 mm)
Height: 30” (762 mm)
Mounting Depth: 2-1/2” (64 mm)
Product Weight:
19 lbs. (8.8 kg) each
Shipping Weight:
44 lbs. (20 kg) per pair
26 lbs. (11.8 kg) per single
