ToP-ART (Total Purity Audio Reproduction Technology) and high quality parts
- I/O (input to output) Direct Symmetrical Design
- ART (Anti-Resolution and Tough) Base
- Custom-made power transformer / 12,000uF block capacitors / Aluminum-extruded heat sinks
160W x 2 (max), 100W x 2 (RMS) high power output
CD Direct Amplification and Pure Direct
Continuous Variable Loudness Control
Gold-plated speaker terminals and RCA terminals
Digital audio inputs for TV or Blu-ray Player
Connection for YBA-11 Bluetooth Wireless Adapter
Simple yet sophisticated design (aluminium front panel and knobs)
Auto Power Standby
Specifications:-
Minimum RMS Output Power: (8 ohms, 20 Hz-20 kHz)
100 W + 100 W (0.019% THD)
Maximum Power: (4 ohms, 1kHz, 0.7% THD, for Europe)
160 W + 160 W
High Dynamic Power/Channel: (8/6/4/2 ohms)
140/170/220/290 W
Damping Factor:
240
Frequency Response:
10 Hz-100 kHz +/-1.0 dB
Total Harmonic Distortion: (CD to Sp Out, 20 Hz-20 kHz)
0.019% (50 W/8 ohms)
Signal-to-Noise Ratio (CD):
99dB (input shorted, 200 mV)
Audio In / Out:
8 / 2
Digital Input:
Yes (optical / coaxial)
Subwoofer Out:
Yes
DC out:
Yes
Pure Direct:
Yes
ToP-ART:
Yes
Switchable CD Direct Amplification:
Yes
Standby Power Consumption:
0.5W
Power Management (Auto Power Standby):
Yes
Dimensions (W x H x D):
435 x 151 x 387 mm; 17-1/8” x 6” x 15-1/4”
Weight:
11.2 kg; 24.7 lbs.
